Cable rotary helm UFX Τ67

Cable rotary helm UFX Τ67

The Ultraflex T-67 rotary helm features a standard 3/4' taper to suit Ultraflex, Morse & Teleflex steering wheels. It is generally accepted that the T67 Helm and M-58 Steering cable are adequate for outboard engines up to 55hp however in cases of more frequent and harsher use the T-71/T-73 Ultraflex Helm with M-66 Steering cable would be advisable due to the more robust construction of the helm units. Features:

Corrosion resistant materials
Standard friction externally adjustable 90° bezel
Four optional helm positions to facilitate steering cable installation
Lock-to-lock steering wheel turns: approx. 2-5 Stroke: 230 mm (9')
Maximum allowable steering wheel diameter: 380 mm (15')
Minimum steering cable bend radius: 200 mm (7-9')
Exceeds EN 29775 safety standards for use with outboard engines up to 40 kW (55 hp).
To be used with Ultraflex M58 steering cables

*For boats exceeding 50 mph speed is necessary for safety reasons, the use of hydraulic steering gear*

Installation & maintenance manual

Code

12-0011
